RMUP-300 Series
4
<2> Parts introduction
ALARM OUTPUT TERMINAL
COOLING WATER OUTLET
COOLING WATER INLET
AIR OUTLET
POWER SOCKET
POWER SWITCH
AIR INLET(FILTER GAUZE)
DRAIN
WATER LEVEL GAUGE
WATER INJECTION PORT
