16 S&C Instruction Sheet 1045M-510
Installing the Rotating Switch Operator
Figure 8. The universal joint clamp at the first section of pipe.
24
(610)
24 (610)
44 3/4 (1137)
SINGLE POINT
LIFT BRACKET
5
(127)
2 1/4
(57)
4 15/16 (125)
2 1/8 (54)
30 (762)
MOUNTING
DIMENSION
13/16 (21)2 X
MOUNTING
HOLES
3 11/16 (94)
1 11/16 (43)
1 29/32 (48)
(1 1/2 IPS PIPE)
1.500
(38)
Ø
Ø
Ø
Ø
Figure 9. The rear and front view of the rotating switch operator enclosure, dimensions are
inches (mm).
