Operation
82010-PG, REV. F Sandel SA4550 Pilot’s Guide 2-31
Color Data Displayed
RED
 Flags: ATTITUDE, GS, LOC,
SPEED, COMPUTER
 Chevrons
 CRC Annunciator
YELLOW
 DH Annunciator, GA Annunciator
 Text on GYRO FLAG and ATT
FAIL Annunciator
MAGENTA
 Flight Director Command Bars
 (Single Cue and Dual Cue)
 Fast/Slow Indicator
 Glideslope Deviation Indicator
 Localizer Deviation Indicator
GRAY
 Aircraft Symbol – Single Cue
Operation
82010-PG, REV. F Sandel SA4550 Pilot’s Guide 2-32
Color Data Displayed
BLACK
 Aircraft Symbol – Dual Cue
