SERVICE TOOLS
8.1 Special Service Tools
These tools can be obtained from your local tool supplier.
1. Oil Dipstick 5. Lip Seal / SD7 Seal Plate Tool 9. Rotor Installation Driver
2. Armature Plate Spanner 6. Armature Driver 10. O-Ring Hook
3. Armature Plate Puller 7. Rotor Puller Jaws
4. Rotor Puller Set 8. Shaft Seal Protective Sleeve
8.2 Standard Tools
1. External Snap Ring Pliers 4. Gasket Scraper
2. Internal Snap Ring Pliers 5. Graduated Cylinder
3. Feeler Gauges
