s07nmdl1sm-rev0513 Models S07 Non-Metallic Page 5
*Both Suction and Discharge
Ports are Available In:
¾" BSPT (Tapered) (Internal)
1½" BSPT (Tapered) (External)
Air Inlet ¼" NPT
Manifold Can Rotate 90°
From Vertical Centerline.
*Discharge Port
¾" NPT (Internal)
1½" NPT (External)
Standard
Encapsulated Muffler:
3/8" NPT Exhaust Port
For Optional Muffler
Styles or Piping Exhaust
Air in Submerged
Applications.
*Suction Port
¾" NPT (Internal)
1½" NPT (External)
Bolt Pattern
is Symmetrical
About Centerlines
Dimensions: S07 Non-Metallic
Dimensions in Inches
Dimensional tolerance: ±
1
/8"
Dimension
Standard Pump
Pulse Output Kit
Mesh Mufer
A B
4 1/16" 7 1/16"
4 1/16" 7 1/16"
5 3/4" 9 15/16"
