Sandpiper SB1 User Manual

sb1dl5sm-rev0317
sandpi p erpump .com
Model SB1 & SB25 • 4
"D"
11.36
288
9.00
229
8.56
217
4X
.28 [7] MOUNTING HOLE
NOTE:
UNIT FURNISHED WITH SUB-BASE PLATE
AND RUBBER FEET AS STANDARD. FOR
STATIONARY BOLT DOWN USE, RUBBER
FEET CAN BE REMOVED.
.72
18
.64
16
8.43
214
7.62
194
"A"
"B"
"C"
6.82
173
DISCHARGE PORT
1" NPT (SB1)
1" BSPT (SB25)
SUCTION PORT
1" NPT (SB1)
1" BSPT (SB25)
AIR INLET
1/2" NPT
AIR EXHAUST
3/4" NPT
HEAVY DUTY BALL VALVE PUMP
BOTTOM PORTED
DIMENSIONAL TOLERANCE 1/8 [3]
[XX] = MILLIMETERS
PUMP
COFIGURATION
DIM "A" DIM "B" DIM "C" DIM "D"
ALUMINUM
CENTER SECTION
3.95 [100] 5.86 [149] 15.36 [390] 14.49 [368]
CAST IRON
CENTER SECTION
4.10 [104] 5.54 [141] 15.06 [383] 15.69 [398]
PULSE OUTPUT
CONFIGURATION
"D"
11.36
288
9.00
229
8.56
217
4X
.28 [7] MOUNTING HOLE
NOTE:
UNIT FURNISHED WITH SUB-BASE PLATE
AND RUBBER FEET AS STANDARD. FOR
STATIONARY BOLT DOWN USE, RUBBER
FEET CAN BE REMOVED.
.72
18
.64
16
8.43
214
7.62
194
"A"
"B"
"C"
6.82
173
DISCHARGE PORT
1" NPT (SB1)
1" BSPT (SB25)
SUCTION PORT
1" NPT (SB1)
1" BSPT (SB25)
AIR INLET
1/2" NPT
AIR EXHAUST
3/4" NPT
HEAVY DUTY BALL VALVE PUMP
BOTTOM PORTED
DIMENSIONAL TOLERANCE 1/8 [3]
[XX] = MILLIMETERS
PUMP
COFIGURATION
DIM "A" DIM "B" DIM "C" DIM "D"
ALUMINUM
CENTER SECTION
3.95 [100] 5.86 [149] 15.36 [390] 14.49 [368]
CAST IRON
CENTER SECTION
4.10 [104] 5.54 [141] 15.06 [383] 15.69 [398]
PULSE OUTPUT
CONFIGURATION
UNIVERSAL ALL AODD
1: PUMP SPECS

Sandpiper SB1 Specifications

General

Brand	Sandpiper
Model	SB1
Category	Water Pump
Language	English
