1. About This Manual
This manual contains information necessary for the use of personnel engaged in the
installation and commissioning of the SEC3002 Fire Alarm Control Panel, regarding the
connection of the panel with its peripherals, programming of all the functions, etc.
This document does not cover panel operation or functionality. This data can be found in the
separate Operating Manual.
2. Introduction
2.1 Overview
The purpose of the SEC3002 Fire Alarm Control Panel (FACP) is to monitor input signals, give
indications and possibly activate outputs as programmed. It is designed to comply with EN
54-2 with qualities of simple installation, operation and easy maintenance.
The SEC3002 panel is an addressable fire detection panel with 1 loop of 324 addressable
points and expansion capabilities. It is compatible with other peripherals made by Sanjiang
with its own protocol.
2.2 Technical Specifications
Power supply
Mains supply
220V/230VAC±15%. 47 ~ 63Hz. Max current 0.8A
Mains fuse
T3.15AL250V
Recommended mains cable
Screened cable, cable size 0.75mm
2
Power rating
Imax.a=0.67A; Imax.b=2.6A; Imin=0.35A
Max. charging current
1.2A
Battery capacity, type and
recommended model
Max. capacity 2×12V/17Ah; Min. capacity 2×12V/12Ah
VRLA. PS-12170 for 17Ah (Power-sonic), LCPA1212 for 12Ah
(Panasonic)
Max. internal battery resistance
1Ω
Battery fuse
F8AL250V
Recommended battery cable
14AWG
Quiescent current (full loaded)
< 0.4A
Outputs
S.C. Out (+, -)
Output voltage
18.5
~
27.5VDC
Max. output current
0.5A
Fuse rating
F1AL250V
End of line resistor
4K7
Type of cable
Plain unscreened cable, 1.5mm
2
Cable diameter
1mm
2
~ 2mm
2
Transmission distance
≤
1500m
Max. number of sounders @50mA
20
