6
How to attach the stand
NOTE:
• Unplug the AC cord from the AC INPUT terminal.
• Before beginning this process, assure that TV is laid on a clean, safe, and cushioned space to avoid
any damage to the unit.
• Do not touch or press the TV-screen, glass might break under pressure.
Place the TV on its back onto a table.
Align the stand’s bottom-plate (supplied) as seen here.
It will fi t in only one direction.
Press it in direction of arrow until you hear ‘click’.
Finally secure the bottom-plate with 2 screws
(supplied).
Please assure “ ” mark on the stand is facing the LCD
panel side.
How to remove the stand
When you transport this product, remove the stand and pack fl at against the back of the unit in the
carton. To remove the stand, remove the two (2) screws from the bottom (see A), and hold the stand on a
fl at surface lifting one side of the unit until stand disconnects (see B).
For wall mounting, the base must be removed. To disconnect the base/stand remove the two (2) screws from the
back (see page 5).
AB
