SANTA FE COMPACT INSTALLER'S AND OWNER'S MANUAL
2
Santa Fe Compact Installer’s & Owner’s Manual
Table of Contents
Precautions .........................................................2
1. Intended Application(s) .........................................2
2. Registrations .......................................................2
3. Specications ......................................................3
4. Unit Assembly .....................................................3
4.1 Installing Feet ......................................................3
4.2 Drain Hose ..........................................................3
5. Installation ..........................................................3
5.1 Safety Precautions ..............................................3
5.2 Location ...............................................................3
5.3 Electrical Requirements .......................................3
5.4 Condensate (Water) Removal ...............................3
5.4A Lifting Condesate .................................................4
5.4B Condensate Pump Kit ...........................................4
6. Operation ............................................................4
6.1 Humidity Control Adjustment ...............................4
6.2 Defrost Cycle .......................................................4
6.3 Fan Operation ......................................................4
7. Maintenance .......................................................4
7.1 Air Filters .............................................................5
7.2 Cleaning Pre-lter ...............................................5
7.3 Pleated Filter .......................................................5
7.4 Removing Filters .................................................5
7.5 Installing Filters ...................................................5
8. Service ................................................................5
8.1 Technical Description ..........................................5
8.2 Troubleshooting ...................................................5
8.3 Refrigerant Charging ............................................6
8.4 Compressor/Capacitor Replacement ....................6
9. Replacement Parts/Accessories ..........................6
10. Wiring Diagram ...................................................6
Warranty .............................................................7
Precautions
• Do not operate the Santa Fe Compact with a cut or frayed
power cord.
• Do not unplug the unit by pulling on the cord. Grasp the
plug rmly and pull it out of the wall socket or power
receptacle.
• Always use a grounded outlet.
• Never operate electrical equipment near or in standing
water.
• Do not stick your ngers or other objects through the
safety grill.
• When changing lters, do not stick ngers or other objects
in the unit.
• Do not restrict airow in to or out of the unit. This may
cause the unit to overheat.
• The unit should never be serviced or cleaned while it is
plugged in.
• Do not sit or stand on the unit, or use as a shelf or table.
• Before leaving the unit unattended, ensure children do not
have access to the equipment. Do not allow children to play
with or near the unit or in its air ow.
• The unit is designed to be installed indoors only.
• No user serviceable components. Contact installer or call
1-800-533-7533 for all repair or warranty needs.
Read the installation, operation and maintenance instructions
carefully before installing and using this unit. Proper
adherence to these instructions is essential to obtain
maximum benet from your Santa Fe dehumidier.
Read and Save These Instructions
WARNING! — This symbol means important
instructions. Failure to heed them can result in serious
injury or death.
CAUTION! — This symbol means important
instructions. Failure to heed them can result in injury or
material property damage.
1. Intended Application(s)
The Santa Fe Compact is intended for use in crawlspaces
or basements: however, the unit can be placed in almost
any residential setting where dehumidication is desired.
Use in non-residential applications and pool areas may void
warranty.
The Santa Fe Compact is designed to operate in
temperatures between 49° and 95°F. This unit works most
effectively between 56° and 95°.
In order to efciently control humidity levels, the area in
which the dehumidier is to be operated must be free of
water intrusion or excessive fresh (outside) air inltration.
Before installing the Santa Fe Compact, water intrusion and
air inltration problems should be addressed.
2. Registrations
The Santa Fe Compact conforms to UL STD 474 and CSA
standard C22.2 No. 92.
Thank you for purchasing the Santa Fe Compact. For questions regarding this product
or to order parts/accessories, contact your dealer or call TOLL-FREE 1-800-533-7533.
