Assembling the receiver part (knives) (Fig. H):
1. With a thick cloth, hold the knives (BE CAREFUL there is a risk of cutting yourself).
2. Fit the low nut (19) (left-hand thread) into the hexagonal housing of the hard plastic
coupling (12).
3. Adhering to this order, put the knives (15) back on the shaft, the thin, stainless steel
washer (16) then the fiber washer (17) and finally the wide stainless steel washer
(18).
4. Screw up the coupling (12) counter-clockwise (left hand thread).
TROUBLESHOOTING
Identifying the cause of appliance stoppage with precision.
The appliance does not start:
• Check: the mains supply, the condition of the supply cord (10).
• Version E: the motor will not start unless the bowl assembly (1) is fitted on the
motor unit (2).
The appliance stops after the motor has overheated: (the motor unit is hot)
