Assembling the bearing on the jar
 Place the bearing seal (16) on the bearing (12)
 Place the locking ring seal (18) on the locking ring (17)
 Place the bearing (12) inside the jar (1)
 Screw down the locking ring, take care that the locking ring seal remains in its
seating
 Tighten well by hand, or with a lever
