3
16.00 in
406.4mm
16.73 in
425mm
DETCARTER WEIV EDISDETCARTER - WEIV POTTNUOM DELBMESSA YLLUF
SIDE VIEW - EXTENDED
3-D
TOP VIEW - EXTENDEDWALL PLATE
TV INTERFACE
FLAT SCREEN TV
WALL IS ON TOP
WALL IS ON RIGHTWALL IS ON RIGHT
SIMULATED 75"
WALL IS ON TOP
600mm
23.6 in
MAX
15.75 in
400mm
MAX
200mm
7.87 in
MIN
3.94 in
100mm
MIN
263.1mm
10.36 in
1.77 in
45mm
27.00 in
685.8mm
24 in
609.6mm
42 deg
42 deg
2.26 in
57.5mm
15°
5°
DOWN
UP
Dimensions
BEFORE YOU BEGIN
Remove the stand
from your TV — if attached.
Install any accessories
you may have purchased, if they
require TV removal prior to assembly.
The TV is removable for future
accessory purchases.
Soft clean surface
Protect the face
of your TV when laying it
down for installation.
To Next Page
