Sanus FSF207 - Step 2 A: Wood Stud Installation - Mounting; Install Wall Plate with Lag Bolts

13
17
16
16
15
15
4
4. Install wall plate assembly
15
using two lag bolts
16
and two washers
17
. Tighten the lag bolts only until they are pulled
firmly against the wall plate.
NOTE: If needed, you can make small level adjustments to the wall plate by loosening the bottom lag bolt and shifting the
wall plate until level. Tighten the bottom lag bolt when adjustments are complete.
CAUTION: Avoid potential personal injury or property damage! All lag bolts MUST BE firmly tightened to prevent
unwanted movement of the wall plate
15
.
Ensure the wall plate is securely fastened to the wall before continuing on to the
next step.
