Sanus OLF24-B2 - Page 11

11
5/16 x 3 1/2 in.
M8 X 12 mm
5/16 in.
1/4 in.
1/4-20 x 3/8 in.
1/4-20 x 5/8 in.
3/16 in.
M6/M8
2.5mm
5mm
22mm
M8 x 50mm
M6 x 12mm
M6 x 35mmM6 x 20mm
M8 x 20mm
M8 x 40mm
M8x30 mm
Parts and Hardware for STEP 2
Concrete Anchors
For concrete installations ONLY
CAUTION: Do not use in drywall or wood
Fischer UX10 x 60R
Wall Plate
Wall Plate Template
Lag Bolts
Lag Bolt Washers
STEP 2 Attach Wall Plate to Wall
qty. 1
07
qty. 6
09
qty. 6
10
qty. 6
11
qty. 1
08
