Sanus OLF24-B2 - Page 13

13
Wood Stud Installation
3 4
3½ in. (89 mm)
7/32 in.
(5.5 mm)
09
10
UP ARROW
Install the wall plate
08
using four lag bolts
09
and washers
10
.
Tighten all lag bolts
09
only until the washers
10
are pulled firmly
against the wall plate.
CAUTION: Avoid potential personal injury or property damage!
All four lag bolts
09
MUST BE firmly tightened to prevent unwanted
movement of the wall plate
08
.
Ensure the wall plate is securely
fastened to the wall before continuing on to the next step.
Go to STEP 3 on PAGE 16.
07
08
