Install the four screws
S2
and washers
S3
, and firmly tighten until they are
pulled flush against the wall plate
07
.
6
INSTALL ANCHORS
7
SECURELY TIGHTEN
All four screws
S2
MUST BE firmly tightened to prevent unwanted movement
of the wall plate
07
.
Ensure the wall plate is securely fastened to the wall
before continuing on to the next step.
CAUTION: Avoid potential personal injury or property damage!
S1
a. Insert the four anchors
S1
into the drilled holes. b. Pull to rotate the anchor
S1
inside the wall. c. Hold the end of the anchor
S1
, while sliding the cap
P
against the
drywall. d. Snap o the ends of the anchor
S1
to lock in place.
CAUTION: Be sure cap
P
is
seated against the drywall surface.
S3 S2
