Right TV
Bracket
Left TV
Bracket
M6 x 12mm
M6 x 35mm
M8 x 50mm
M8 x 16mm
M8 x 20mm
M8 x 40mm
M8 x 30mm
5mm2.5mm 22mm
M4 x 12mm
M4 x 35mm
M6 x 20mm
M4 / M5 M6 / M8
TV Washers
TV Brackets
03
x4
04
x4
01
x1
02
x1
Parts and Hardware for STEP 1
TV Screws
*
Attach TV Bracket to TVSTEP 1
WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are
missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts!
NOTE: Not all hardware included will be used.
CAUTION: Avoid potential personal injury or property damage!
The TV brackets contain potential pinch points during operation.
Keep fingers away from pinch points when retracting the TV (arrows)
*
TV Spacers
05
x4
To Next Page
