8
Attach Wall Plate to Wall
STEP 2
5⁄16 x 2 ¾ in.
5⁄16 in.
08
x4
07
x1
06
x1
Parts and Hardware for STEP 2
Lag Bolt
Wall Plate
Wall Plate Template
Hex Key
in.
WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any
parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service.
Never use damaged parts!
NOTE: Not all hardware included will be used.
09
x4
Washer
10
x1
CAUTION: Do not use in drywall or wood
STEP 2C: Steel Stud Installation Kit SSMK1 (NOT INCLUDED)
Contact Customer Service at 1-888-333-1376 to inquire about the additional hardware.
1/4-20 x 1 ¾ in.
1/4 in.
x4
S1
x4
S2
x4
S3
1/4-20 SNAP Toggle BB
.734 x .312 x .065 in.
STEP 2B: Concrete Installation Kit CMK1 is NOT INCLUDED
Contact Customer Service at 1-888-333-1376 to inquire about the
additional hardware.
Concrete
Anchor
Fischer UX10 x 60R
C1 x4
For concrete installations ONLY
To Next Page
