Sanus SLT4 - Attaching TV Bracket Assembly; Position Brackets; Securely Tighten

7
01
02
4X
2
SECURELY TIGHTEN
b
Rounded-back TVs / Extra Space
04
a
Flat-back TVs
04
03 03
05
Install using the spacer, screw and washer combination you selected for your TV.
1.3 Attach TV Bracket Assembly to TV
Center the TV brackets
01
and
02
over your TV's mounting hole pattern -
making sure the brackets are at the same height.
Adjust the release tabs
R
to the bottom of the TV.
1
POSITION
TIP:
The tilt tension knob
T
on TV brackets
01
and
02
should be oriented to
the outside edges.
T
T
T
R
R
TV
