All four lag bolts
17
MUST BE firmly tightened to prevent
unwanted movement of the wall plate
15
.
Ensure the wall plate is
securely fastened to the wall before continuing on to the next step.
CAUTION:
Avoid potential personal injury or property damage!
15
4X
17
14
18
4X
CAUTION:
Be sure the anchors
18
are seated fl ush
with the concrete surface.
CAUTION:
Install the four lag bolts
17
. Firmly tighten all four lag bolts
17
until
they are pulled flush against the wall plate/arm assembly
15
.
Insert four anchors
18
.
34
INSERT ANCHORS
5
SECURELY TIGHTEN
