Never drill into the mortar between blocks.
CAUTION:
Never drill into the mortar between blocks.
3
DRILL
4X
4X
CAUTION:
TIP:
TIP:
To calculate your precise wall plate location, check out
our HeightFinder at sanus.com [www.sanus.com/1172].
Min. 24 in. (61.0 cm)
3/8 in.
(10 mm)
3 ¾ in. (9.5 cm)
Position the wall plate template
14
on the wall at your desired height.
Level and tape in place.
.
Drill four pilot holes using a 3/8 in. (10 mm) diameter drill bit.
IMPORTANT: Pilot holes must be drilled to a depth of 3 ¾ in. (9.5 cm).
sanus.com
/1172
HeightFinder™
Visit
STEP 2B (continued)
2
POSITION TEMPLATE
To Next Page
