Sanyo C0951 - Dimensional Data

13
31-11/16 (805)
10-5/8 (270)
6-31/32 (177)
3-29/32
(99.5)
2-5/16
(58.5)
1-5/8 (41.0)
1-5/8 (41.0)
Drain hose ø23/32 (18)
Narrow tube ø1/4 (6.35)
Wide tube*
Center of tubing
hole (2 places)
Unit: inch (mm)
6-7/32
(172.5)
Remote control unit
2-2/5
(61)
25/32
(18.5)
KS0951
KS1251
ø3/8 (9.52)
ø1/2 (12.7)
*
3. DIMENSIONAL DATA
3-1. Unit
3-1-1. Indoor Unit
(1) Indoor unit KS0951 / KS1251
