9
DATA SUBJECT TO CHANGE WITHOUT NOTICE.
(2) Outdoor unit CH1251
Control PCB
Part No. POW-CH095
Controls —
Control circuit fuse —
Compressor
Type Rotary (Hermetic)
Compressor model C-R95H2E
Nominal output W 950
Compressor oil … Amount cc SUNISO 4GSD-T … 570
Coil resistance (ambient temp. 68°F (20°C)) Ω C – R: 0.576
C – S: 3.070
Safety devices Type External (OLR)
Overload relay MRA98693-9200
Run capacitor µF 40
VAC 400
Crank case heater 115V, 20W
Heat Exchanger Coil
Coil Aluminum plate fin / Copper tube
Rows 2
Fin pitch inch (mm) 1/16 (1.4)
Face area ft
2
(m
2
) 3.37 (0.313)
External Finish Acrylic baked-on enamel finish
Fan & Fan Motor
Type Propeller
Q’ty … Dia. and length inch. (mm) 1 … 16-17/32 (ø 420)
Fan motor model … Q’ty UE6-21BA1PA … 1
No. of poles … rpm (115V, High) 6 … 630
Nominal output W 20
Coil resistance (ambient temp. 68°F (20°C)) Ω BLU – BRN: 45.3
BLU – PNK: 50.5
Run capacitor µF 8
VAC 220
000-111 SM (1-17) 00.3.17 11:44 AM y[W 9
