PARTS LIST
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE IEC
SYMBOL
!
!!
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY CAN BE OF
SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY
!
!!
, USE ONLY THE REPLACEMENT PARTS DESIGNATED,
OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE DESIGNATED IN THE PARTS LIST
IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE MADE TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE PRODUCT TO THE CUSTOMER.
CAUTION : Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W Carbon type and Chip type resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type, Electrolytic type and Chip type.
PACKING & ACCESSORIES
REF.NO. PART NO. DESCRIPTION
614 318 0616 CARTON CASE,
OUTER CARTON(DC-X8CT/UK)
614 318 0623 CARTON CASE,
OUTER CARTON(DC-X8CM/UK)
614 317 8040 CARTON CASE,
OUTER CARTON(DC-088C/XE)
614 319 0974 CARTON CASE,
OUTER CARTON(DC-088C/SP)
614 318 0647 CUSHION,SPACE,ACCESSORY
(DC-X8CT/UK & DC-X8CM/UK)
614 317 8071 CUSHION,SPACE,ACCESSORY
(DC-088C/XE & DC-088C/SP)
614 317 7913 CARTON CASE,INNER SLEEVE
(DC-X8CT/UK & DC-X8CM/UK)
614 317 7937 CARTON CASE,INNER SLEEVE
(DC-088C/XE)
614 319 0936 CARTON CASE,INNER SLEEVE
(DC-088C/SP)
614 316 2766 CUSHION,FRONT
614 316 2773 CUSHION,BACK
614 317 8149 INSTRUCTION MANUAL
(DC-X8CT/UK & DC-X8CM/UK)
614 317 9177 INSTRUCTION MANUAL
(DC-088C/XE& DC-088C/SP)
614 317 9184 INSTRUCTION MANUAL GREEK
(DC-088C/XE)
614 245 8587 NOTICE,AC CORD
(DC-X8CT/UK & DC-X8CM/UK)
645 047 3050 POLY SHEET-0650X0450*NC,SET
(DC-X8CT/UK & DC-X8CM/UK
& DC-088C/SP)
645 047 3067 POLY SHEET-0650X0450*NC,SET
(DC-088C/XE)
614 316 7150 ASSY,BOX,SPEAKER
(DC-X8CT/UK & DC-X8CM/UK)
614 316 7730 ASSY,BOX,SPEAKER
(DC-088C/XE& DC-088C/SP)
614 316 7167 ASSY,GRILLE
(DC-X8CT/UK & DC-X8CM/UK)
614 319 2817 ASSY,GRILLE
(DC-088C/XE& DC-088C/SP)
645 005 1227 ASSY,ANTENA,LOOP
614 229 4635 ANT,FM ANT
or 614 308 5515 ANT,FM ANT
645 045 7425 REMOCON,RB-X8RD
645 040 9943 BATTERY COVER,SERVICE PART
645 047 1469 CABLE,SYSTEM 19P,SYSTEM CABLE
(DC-X8CT/UK)
645 047 7058 ASSY,CABLE,SYSTEM,19P
(DC-X8CM/UK)
645 043 9421 CABLE,OPTICAL (DC-X8CM/UK)
645 047 6594 ASSY,CABLE,SYSTEM,19P
(DC-088C/XE)
645 048 5992 ASSY,CABLE,SYSTEM,19P
(DC-088C/SP)
CABINET & CHASSIS
REF.NO. PART NO. DESCRIPTION
1 614 316 5378 ASSY,CABINET,FRONT
(DC-X8CT/UK & DC-X8CM/UK)
1 614 317 9153 ASSY,CABINET,FRONT
(DC-088C/XE)
1 614 319 0578 ASSY,CABINET,FRONT
(DC-088C/SP)
2 614 316 2490 KNOB,ROTARY,VOL,VOLUME
3 614 316 2506 KNOB,ROTARY,JOG,JOG
4 614 302 0530 DEC,WINDOW LED,STANDBY
5 614 316 2025 BUTTON,STANDBY(DC-X8CT/UK,
DC-X8CM/UK & DC-088C/XE)
5 614 319 0646 BUTTON,STANDBY
(DC-088C/SP)
6 614 316 2049 BUTTON,MEMORY,BAND
7 614 316 2032 BUTTON,BAND,BAND
8 614 316 2308 DEC,WINDOW,VOL,VOL LIGHTING
9 614 316 3350 REFLECTOR,LED,VOL LIGHTING
10 614 316 2056 BUTTON,JOG MODE(DC-X8CT/UK,
DC-X8CM/UK & DC-088C/XE)
10 614 319 0653 BUTTON,JOG MODE(DC-X8CT/UK,
(DC-088C/SP)
11 614 317 7401 ASSY,CABINET,BENDING,
AFTER BENDING
12 614 316 2476 HOLDER,HEAT SINK,LEFT,HEATSINK
13 614 316 2483 HOLDER,HEAT SINK,RIGHT,HEATSINK
14 614 316 5439 ASSY,HEAT SINK,POWER IC, TR
15 614 291 6568 MOUNTING,PWB,FOR-REG
16 614 316 1264 ASSY,CABINET,BOTTOM
17 614 129 1901 FIXER,AC CORD
or 614 284 1884 FIXER,AC CORD
18 614 310 3837 MOUNTING,FAN
19 614 316 2537 PANEL,REAR
20 614 317 9160 REFLECTOR,SHEET,VOL LIGHTING
21 614 317 4721 SHIELD,FRONT
N.S.P : Not supplied as service parts.
FIXING PARTS
REF.NO. PART NO. DESCRIPTION
Y01 411 021 6405 SCR S-TPG BIN 3X8,
FRONT-BOTTOM FIX
Y02 411 165 3803 SCR S-TPG BIN 2.3X10,
FRONT PWB FIX
Y03 411 098 4205 SCR S-TPG BIN 3X8,CABINET
Y04 411 021 6405 SCR S-TPG BIN 3X8,
HOLDER HS-BOTTOM
Y05 411 021 6405 SCR S-TPG BIN 3X8,
HOLDER HS-HEATSINK
Y06 411 021 6405 SCR S-TPG BIN 3X8,
HEATSINK-POSISTOR
Y07 411 021 6405 SCR S-TPG BIN 3X8,TUNER PWB
Y08 411 021 6405 SCR S-TPG BIN 3X8,HOLDER HS-PWB
+MAIN PWB
Y09 411 020 9506 SCR S-TPG BRZ+FLG 3X16,
HEATSINK-POWER IC
To Next Page
