Sanyo DC-088C User Manual

- 54 -
EXPLODED VIEW (TAPE MECHANISM)
TAPE MECHANISM (TM-X8SM-SH)
REF.NO. PART NO. DESCRIPTION
TM00 614 316 7822 ASSY,MECHA,TM-X8SM-SH
TM01 645 047 2930 ASSY,MECHA ADR2174TB3
TM02 645 047 1032 GEAR LUCK
TM03 645 047 1070 BELT D49.2
TM04 645 047 0981 ASSY,MOTOR PCB
TM05 645 047 2633 DC MOTOR ASSY
TM06 645 047 2596 PINCH ROLLER ASSY (R)
TM07 645 047 2589 PINCH ROLLER ASSY (F)
TM08 645 047 2626 HEAD ASSY
TM09
TM10
TM08
TM07
TM06
TM05
TM04
TM03
TM02
TM01
IC BLOCK DIAGRAM & DESCRIPTION
16 15 14 13 12 11 10 9
87654321
V
CC V CC /2 NR SW LINE
OUT 2
TC 2 REC
OUT 2
PB
IN 2
REC
IN 2
+
+
ATT3
ATT3
ATT1
ATT1
DET
DET
ATT2
ATT2
SC
SC
GND IREF
MODE
SW
LINE
OUT 1 TC 1
REC
OUT 1
PB
IN 1
REC
IN 1
ATT : Attenuator
SC : Side Chain
DET : Detector
IC351 CXA1552P
(Dolby B type Noise Reduction System)
IC362 BA3126N (2-channel head switch for
radio cassette recorders )
1
8
7
6
5
4
3
2
9
GND
REC. SW
P/B SW
CONT
REC. SW
P/B. SW
VCC
GND
GND
IC371 KIA4580L
(Dual Operation Amplifier)
1
2
3
5
6
7
8
4
V(+)
A OUTPUT
A
B
B OUTPUT
B -INPUT
B +INPUT
A -INPUT
A +INPUT
V(-)
A
B
OUT A OUT B
-IN A
+IN A
V
EE
V
CC
V
CC
+IN B
-IN B
12
3
4
5
6
7
8
9
IC451 KIA4558S
(Dual Low Noise Operational Amplifier)
