FILE NO.
REVISION-1
Category: Colour Television Chassis Series: UE5-A
Model: LCD-32K30TD Efective from: Service Ref. No. LCD-32K30TD-00
Destination: Australia Reference No: SM3010412 Issue Date: Apr., 2009
FILE WITH ORIGINAL SERVICE MANUAL.
Product Code: 113 017 811
Please add this notice to the Manuals listed below.
REFERENCE NO. SM3010412-01
N6WMA
Differences (Panel change)
The reason of change. A: Misprint B: Quality Reliabilities C: Standardization
D: Design
Give complete “SERVICE REF. No. ” for parts order or servicing. It is shown on the rating label at
the cabinet back of the unit. Refer to SM3010412 (Issue date: Apr., 2009) Service Manual for all
the item not given in this notice.
Old 645 098 7885 LCD(LC320WXN-SBA1)
New 645 098 7793 LCD(T315XW02 VS)
EL901
Page &
Section
Key No.
Part No.
Description
Q’ty
Interchange-
ability
Reason
D
Page 18
1NO
D
1NO
1NO
D
1NO
1NO
W7300
Old 652 002 6094 CORD 50PIN (LVDS)
New OMITTED
Page 22
--
Old 610 344 8640 ASSY, PWB, MAIN N6WM
New 610 346 4251 ASSY, PWB, MAIN N6WMA
IC5750
Old 409 689 2511 IC W25X32VSSIG-N6WM
New 410 693 4306 IC W25X32VSSIG-N6WMA
Page 24
1NO
1NO
D
C1507
Old NOT USED
New 404 104 4900 CERAMIC 0.1UK 50V
404 091 2606 CERAMIC 0.1UK 50V
403 367 0417 CERAMIC 0.1UK 50V
Page 25
1NO
1NO
D
To Next Page
