3.2 Alignment flow chart shown as Fig. 1
Fig. 1 Alignment flow chart
Check if DDC, HDCP KEY, FLASH have been burned?
Combination alignment for general assembly
White balance alignment
Connect to central signal source, check if TV functions are normal-omitted channel, analog
parameters control, etc.? Check if the output of earphones and speakers are normal?
Input high-definition component signal (mode), check YPbPr functions are normal?
Input VGA signal, check if display and other functions are
normal - analog parameters control, H/V center, etc.?
Input AV signal, check if AV functions are normal?
Setup before shipment
Accessories checkup and packing
Input HDMI signal, check if display and other functions are
normal - analog parameters control, H/V center, etc.?
To Next Page
