7
Components on PCB
CN8
To Battery
Battery Switch
CN1
To Switching
Power supply
CN2
To MTR-480
(Option)
CN4
#1-#2
To Temp. control relay
CN3
To Remote alarm terminal
CN5
#1-#6 To Display PCB(CN51)
#7-#8 To Buzzer
CN7
#9-#10
To Temp.sensor
CN6
To Display PCB (CN52)
