Sanyo MDF-137 User Manual

2
Specifications
䂓Structural specifications
Item Specifications
Name Biomedical Freezer
Model MDF-137
External dimensions W640 x D687 x H881 mm
Internal dimensions W525 x D440 x H715 mm
Effective capacity 138 L
Exterior Painted steel
Interior Colored aluminum plate
Insulation Rigid polyurethane foamed-in place
Door Painted steel
Lock 1 pc, cylinder type
Compressor Hermetic type, Output: 150W
Evaporator Aluminum tube on sheet type
Condenser Wire and tube type
Refrigerant R-134a
Battery
For power failure alarm, Nickel-metal-hydride battery, DC6V, 1100mAh
Automatic charge
Accessories
1 set of key, 1 scraper, 2 baskets
Caster 4 pcs
Leveling foot 2 pcs at front
Access port
㱢17mm at right side and bottom left
Weight 52 Kg
Optional components
Automatic temperature recorder: MTR-4015LH, MTR-G85
Mounting kit for automatic temperature recorder:
MDF-S3040 (for MTR-4015LH)
MDF-S740䋨for MTR-G85䋩
2 baskets: MDF-13B2
MTR-480C
MTR-L03
MTR-5000
䂓Performance specifications
Item Specifications
Cooling performance
-30㷄䋨AT:35㷄, no load䋩
Temperature control range
-20䌾-30㷄
Rated voltage AC220V AC230V AC240V
Rated frequency 50Hz 50Hz 50Hz
Rated power consumption 95W 100W 100W
Noise level 35 dB <A> (background noise; 20dB)
Maximum pressure 1.64 MPa
