Sanyo MDF-C2156VAN Service Manual

12
Electric parts
Compressor (H), (L)
Type KS370J1NS-7A KS370J1NS-4A KS370J1NS-4A1
Parts code 7FB 0 M101 001 06 7FB 0 M101 001 04 7FB 0 M101 001 05
Rated voltage 220V, 60Hz 220/230V, 50Hz 230/240V, 50Hz
Winding resistance䋨C-S) 1.64㱅 2.53ȍ 2.53ȍ
Winding resistance䋨C-R) 3.35ȍ 4.8ȍ 4.8ȍ
Starting relay (H), (L)
Type AMVL-300A AMVL-300A AMVL-300A
Pick-up voltage 215~247VAC 185~217VAC 185~217VAC
Drop-out voltage 69~132VAC 60~120VAC 60~120VAC
Parts code 626 100 1503 626 100 1503 926 100 1504
Overload relay (H), (L)
Type MRA999549201 MRA999539201 MRA999539201
Action to temp. (no current) ON:69㫧10㷄 OFF:135㫧10㷄 ON:69㫧10㷄 OFF:135㫧10㷄 ON:69㫧10㷄 OFF:135㫧10㷄
Action to current (AT25㷄) 29.5A 22.5A 22.5A
Operation time 6~16 sec. 6~16 sec. 6~16 sec.
Parts code 624 226 3173 624 226 3166 924 226 3167
Starting capacitor (H), (L)
Type 160UF, 250V 100UF, 250V 100UF, 250V
Running capacitor (H), (L)
Type 25UF, 400VAC 25UF, 400VAC 25UF, 400VAC
Condensing fan motor
Type SE4-E11L5P SE4-E11L5P SE4-E11L5P
Rated voltage 220-240V 220-240V 220-240V
Parts code 624 224 0167 624 224 0167 924 224 0168
Cap.tube heater
Rated voltage 100V, 15.7W 100V, 15.7W 100V, 15.7W
Resistance䋨25㷄) 638㱅 638㱅 638㱅
Parts code 624 030 2492 624 030 2492 924 030 2493
Temp. control relay (H)
Type G4F-11123T G4F-11123T G4F-11123T
Rated voltage 20A, 12VDC 20A, 12VDC 20A, 12VDC
Parts code 624 173 2397 624 173 2397 924 173 2398
Heater relay
Type G2R-1A-T G2R-1A-T G2R-1A-T
Rated voltage 12V, 1-A, 250V 12V, 1-A, 250V 12V, 1-A, 250V
Parts code 624 188 9299 624 188 9299 924 188 9290
Temp. control relay (L)
Type G4F-11123T G4F-11123T G4F-11123T
Rated voltage 20A, 12VDC 20A, 12VDC 20A, 12VDC
Parts code 624 173 2397 624 173 2397 924 173 2398
Switching power supply
Type ZWS15-12/J ZWS15-12/J ZWS15-12/J
Rated voltage 15W, 12V 15W, 12V 15W, 12V
Parts code 624 227 1291 624 227 1291 924 227 1292
Transformer
Type ATR-C50 ATR-C50 ATR-C50
Rated voltage 200-240V 200-240V 200-240V
Parts code 624 006 0408 624 006 0408 924 006 0409
Pressure switch
Type SNS-C135Q002 SNS-C135Q002 SNS-C135Q002
Rated voltage OFF:2.75MPA ON:0.78MPA OFF:2.75MPA ON:0.78MPA OFF:2.75MPA ON:0.78MPA
Parts code 624 227 0959 624 227 0959 924 227 0950
Door switch
Type SS160-A15 SS160-A15 SS160-A15
Rated voltage 28V, 50MA 28V, 50MA 28V, 50MA
Parts code 624 197 1925 624 197 1925 924 197 1926
Temp. sensor
Type PT-1000㱅 PT-1000㱅 PT-1000㱅
Transformer
Type S41-RN98PV S41-RN98PV S41-RN98PV
Rated voltage P:100V, 9V, 0.46A P:100V, 9V, 0.46A P:100V, 9V, 0.46A
Parts code 624 227 0836 624 227 0836 924 227 0837
Battery switch
Type SLE6A2-5 SLE6A2-5 SLE6A2-5
Rated voltage 4A, 250VAC 4A, 250VAC 4A, 250VAC
Parts code 624 213 1472 624 213 1472 924 213 1473
Battery
Type LC-P067R2J LC-P067R2J LC-P067R2J
Rated voltage 6V, 7.2AH 6V, 7.2AH 6V, 7.2AH
Parts code 624 227 0843 624 227 0843 924 227 0844
Cascade sensor
Type 502AT 502AT 502AT
Rated voltage 5K㱅, 25㷄 5K㱅, 25㷄 5K㱅, 25㷄
Filter sensor
Type 502AT 502AT 502AT
Rated voltage 5K㱅, 25㷄 5K㱅, 25㷄 5K㱅, 25㷄
AT sensor
Type 502AT 502AT 502AT
Rated voltage 5K㱅, 25㷄 5K㱅, 25㷄 5K㱅, 25㷄
Remote switch
Type HLS208N HLS208N HLS208N
Rated voltage 250VAC, 6A 250VAC, 6A 250VAC, 6A
Parts code 624 169 9690 624 169 9690 924 169 9691
Solenoid valve
Type X8263205LT X8263205LT X8263205LT
Rated voltage 24VDC 24VDC 24VDC
Parts code 624 226 8215 624 226 8215 924 226 8216
Back up switch
Type HLS208N HLS208N HLS208N
Rated voltage 250VAC, 6A 250VAC, 6A 250VAC, 6A
Parts code 624 169 9690 624 169 9690 924 169 9691
Test switch
Type 8R2021 8R2021 8R2021
Rated voltage 3A, 125VAC 3A, 125VAC 3A, 125VAC
Parts code 624 194 3984 624 194 3984 924 194 3985
MDF-C2156VAN/2156VANC 230/240V, 50Hz220V, 60Hz 220V, 50Hz
