Specifications
㩷
ŶStructural specifications
Item MDF-C2156VAN MDF-C2156VANC
Name Ultra-Low Temperature Freezer
External dimensions W1730 × D765 × H1010 (mm)
Internal dimensions W760 × D495 × H615 (mm)
Effective capacity 231 L
Exterior Painted steel
Interior Aluminum plate
Outer lid Painted steel
Insulation Vacuum insulation panel + Rigid polyurethane foamed-in place
Access port
㱢40mm, 1 place in the side table
Cooling circuit 2-stage cooling circuit and Low stage Auto cascade system
Compressor High stage side; Hermetic type, Output; 1100W
Low stage side; Hermetic type, Output; 1100W
Evaporator High stage side; Cascade condenser type
Low stage side; Tube on sheet type
Condenser High stage side; Fin and tube type
Low stage side; Shell and tube type, and Wire tube type
Refrigerant H stage side; R-407D
L stage side; HFC mixed refrigerant
Refrigerating oil Ze-NIUS32SA
Power supply Local voltage
Battery Lead storage battery, 6VDC, 7.2Ah x 4pcs, Auto-recharge
Weight 318 kg 325kg
Voltage booster None Built-in
Accessories 1 set of key for outer door latch, 1 set of key for panel door,
6 recording chart rolls, 1 dry cell
1 set connect tube for back-up system
Optional component
Automatic temperature recorder + Mounting kit (MTR-155H+MDF-S30150)
Liquid nitrogen gas container (MDF-135N)
Interface board (MTR-480)
