14
Specification of sensor
1. Following shows temperature and resistance values in thermistor sensor (502AT-1).
㷄 kȍ 㷄 kȍ 㷄 kȍ 㷄 kȍ
䋭50 154.5 䋭36 71.80 䋭22 35.65 0 13.29
䋭49 145.9 䋭35 68.15 䋭21 33.99 5 10.80
䋭48 137.8 䋭34 64.71 䋭20 32.43 10 8.84
䋭47 130.2 䋭33 61.48 䋭19 30.92 15 7.20
䋭46 123.1 䋭32 58.43 䋭18 29.50 20 6.01
䋭45 116.5 䋭31 55.55 䋭17 28.14 25 5.00
䋭44 110.2 䋭30 52.84 䋭16 26.87 30 4.17
䋭43 104.4 䋭29 50.23 䋭15 25.65 35 3.50
䋭42 98.87 䋭28 47.77 䋭14 24.51 40 2.96
䋭41 93.70 䋭27 45.45 䋭13 23.42 45 2.51
䋭40 88.85 䋭26 43.26 䋭12 22.39 50 2.13
䋭39 84.18 䋭25 41.19 䋭11 21.41 55 1.82
䋭38 79.80 䋭24 39.24 䋭10 20.48 60 1.56
䋭37 75.67 䋭23 37.39 䋭5 16.43 65 1.35
2. Following shows temperature㩷䋨-170㷄䌾0㷄䋩㩷 and resistance values in temp. sensor (Pt1000ȍ).
䋨㷄䋩
0 -1 -2 -3 -4 -5 -6 -7 -8 -9
-170 330.4 326.2 322.1 318.0 313.8 309.7 305.5 301.4 297.3 293.1
-160 371.4 367.3 363.2 359.1 355.0 350.9 346.8 342.7 338.6 334.5
-150 412.2 408.2 404.1 400.0 395.9 391.9 387.8 383.7 379.6 375.5
-140 452.8 448.7 444.7 440.6 436.5 432.5 428.5 424.4 420.4 416.3
-130 493.0 489.0 485.0 481.0 477.0 472.9 468.9 464.9 460.8 456.8
-120 533.1 529.1 525.1 521.1 517.1 513.1 509.1 505.1 501.1 497.1
-110 572.9 569.0 565.0 561.0 557.0 553.0 549.1 545.1 541.1 537.1
-100 612.6 608.6 604.6 600.7 596.7 592.8 588.8 584.8 580.9 576.9
-90 652.0 648.1 644.1 640.2 636.2 632.3 628.4 624.4 620.5 616.5
-80 691.3 687.3 683.4 679.5 675.6 671.6 667.7 663.8 659.9 655.9
-70 730.3 726.4 722.5 718.6 714.7 710.8 706.9 703.0 699.1 695.2
-60 769.3 765.4 761.5 757.6 753.7 749.8 745.9 742.0 738.1 734.2
-50 808.1 804.2 800.3 796.4 792.6 788.7 784.8 780.9 777.0 773.2
-40 846.7 842.8 839.0 835.1 831.3 827.4 823.5 819.7 815.8 811.9
-30 885.2 881.4 877.6 873.7 869.8 866.0 862.1 858.3 854.4 850.6
-20 923.6 919.8 915.9 912.1 908.3 904.4 900.6 896.7 892.9 889.1
-10 961.9 958.0 954.2 950.4 946.6 942.7 938.9 935.1 931.3 927.4
0 1000.0 996.2 992.4 988.6 984.8 980.9 977.1 973.3 969.5 965.7
