15
2. Following shows temperature㩷䋨0㷄䌾100㷄䋩㩷 and resistance values in temp. sensor (Pt1000ȍ).
䋨㷄䋩 0 1 2 3 4 5 6 7 8 9
0 1000.0 1003.8 1007.6 1011.4 1015.2 1019.0 1022.8 1026.6 1030.4 1034.2
10 1038.0 1041.8 1045.6 1049.4 1053.2 1057.0 1060.8 1064.6 1068.4 1072.2
20 1076.0 1079.7 1083.5 1087.3 1091.1 1094.9 1098.7 1102.4 1106.2 1110.0
30 1113.8 1117.5 1121.3 1125.1 1128.8 1132.6 1136.4 1140.1 1143.9 1147.7
40 1151.4 1155.2 1159.0 1162.7 1166.5 1170.2 1174.0 1177.7 1181.5 1185.2
50 1189.0 1192.7 1196.5 1200.2 1204.0 1207.7 1211.5 1215.2 1219.0 1222.7
60 1226.4 1230.2 1233.9 1237.6 1241.4 1245.1 1248.8 1252.6 1256.3 1260.0
70 1263.8 1267.5 1271.2 1274.9 1278.7 1282.4 1286.1 1289.8 1293.5 1297.2
80 1301.0 1304.7 1308.4 1312.1 1315.8 1319.5 1323.2 1326.9 1330.6 1334.3
90 1338.0 1341.7 1345.4 1349.1 1352.8 1356.5 1360.2 1363.9 1367.6 1371.3
100 1375.0 1378.7 1382.4 1386.1 1389.8 1393.4 1397.1 1400.8 1404.5 1408.2
