Sanyo PLC-XT20 - Polarized unit (IN)

MZ7-XT2500, MZ7-XT25L00, KC6-XT2000, KC6-XT20L00
-133-
Mechanical Parts List
POL
POL
W
V
Red polarized unit (IN)
Green polarized unit (IN)
Blue polarized unit (IN)
Polarized unit (IN)
S04
M04
M05
M09
L03: R
L04: G
L05: B
TH902
L07: R
L08: G
L09: B
Note:
Only the Blue panel assy
provides TH902 and M09.
POL
WV
Note:
L03, L04 and L05 differ with parts according to
type of LCD panel/prism assembly.
