Sanyo PLC-XU350A Service Manual

Key No. Part No. Description Key No. Part No. Description
KF5-XU350A00 , KA5-XU300A00
Electrical Parts List
-90-
655 003 4410 ASSY,PWB,RC KF5AE
CAPACITOR
C2901 403 455 1012 CERAMIC 1U K 10V
303 433 1112 CERAMIC 1U K 10V
C2902 303 453 8719 CERAMIC 470P K 50V
303 453 9211 CERAMIC 470P K 50V
303 282 5118 CERAMIC 470P K 50V
C2903 303 358 3215 CERAMIC 10U K 6.3V
303 370 0018 CERAMIC 10U K 6.3V
303 368 7319 CERAMIC 10U K 6.3V
C8833 303 453 8917 CERAMIC 0.1U K 16V
303 453 8610 CERAMIC 0.1U K 16V
303 409 3426 CERAMIC 0.1U K 16V
RESISTOR
R2901 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
R2903 301 224 8814 MT-GLAZE 100 JA 1/16W
R8831 301 225 8110 MT-GLAZE 10 JA 1/16W
R8832 301 225 8110 MT-GLAZE 10 JA 1/16W
MISCELLANEOUS
A2901 652 002 3352 UNIT,REMOCON,RECEIVER
SC2091 945 076 3503 SURGE-ABSORBER
SC2092 945 076 3503 SURGE-ABSORBER
655 003 4540 ASSY,PWB,ID CONNECT KF5AE
RESISTOR
R8738 301 226 1516 MT-GLAZE 0.000 ZA 1/16W
COIL
L8731 945 086 6037 IMPEDANCE,330 OHM P
L8732 945 086 6037 IMPEDANCE,330 OHM P
L8733 945 086 6037 IMPEDANCE,330 OHM P
L8734 945 086 6037 IMPEDANCE,330 OHM P
L8737 945 086 6037 IMPEDANCE,330 OHM P
PACKING MATERIALS
610 347 6933 CARTON CASE-KF5AE
(For KF5-XU350A00)
610 347 6940 CARTON CASE-KA5AE
(For KA5-XU300A00)
610 340 0297 POLY BAG-KB3AC
610 344 5762 CUSHION SPACER-KG5AC
610 343 1659 CUSHION TOP-KG5AC
610 343 1642 CUSHION BTM-KG5AC
ACCESSORIES
OWNER'S MANUAL
610 343 6456 CD-ROM(PJ NW MANAGER)
610 347 6889 CD-ROM,OWNERS MANUAL-KF5AE
655 003 3475 SAFETY MANUAL-KG5AC
655 003 2881 SETUP INST-KF5AE
REMOTE CONTROL
645 099 3213 ASSY,REMOCON CXZR
610 344 9944 RC-BATTERY LID-MXAC
AC CORD
!US 645 093 3028 CORD,POWER-2.3MK,US
!EU 645 093 2984 CORD,POWER-2.3MK,EU
!UK 645 093 3004 CORD,POWER-2.3MK,UK
MISCELLANEOUS
610 343 0249 STRAP CAP-KT7AC
610 342 8024 CARRY BAG-KL6A
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
