-11-
Initial
ItemNo. Name Device PC YCbCr Video Detail
480i(+) 480p(+) NTSC PAL Note: 480i(+) = 480i & 575i, 480p(+) = 480p & HDTV
326 Expand Ratio (Horizontal) 1035i PIXEL 23 N/A 23 N/A
327 Position (Horizontal) 1035i PIXEL 510 N/A 528 N/A
328 Position (Vertical) 1035i PIXEL 382 N/A 382 N/A
329 Expand Ratio (Vertical) 1080i PIXEL 7 N/A 7 N/A For Component mode and RGB HDTV 1080i
330 Expand Ratio (Horizontal) 1080i PIXEL 22 N/A 23 N/A
331 Position (Horizontal) 1080i PIXEL 508 N/A 528 N/A
332 Position (Vertical) 1080i PIXEL 382 N/A 383 N/A
333 Expand Ratio (Vertical) 60Hz PIXEL 7 N/A For RGB NTSC 480i
334 Expand Ratio (Horizontal) 60Hz PIXEL 36 N/A
335 Position (Horizontal) 60Hz PIXEL 517 N/A
336 Position (Vertical) 60Hz PIXEL 383 N/A
337 Expand Ratio (Vertical) 50Hz PIXEL 20 N/A For RGB PAL 575i
338 Expand Ratio (Horizontal) 50Hz PIXEL 40 N/A
339 Position (Horizontal) 50Hz PIXEL 515 N/A
340 Position (Vertical) 50Hz PIXEL 384 N/A
341 Expand Ratio (Vertical) 50Hz PIXEL 7 N/A 7 N/A For 1080i_50Hz and RGB HDTV 1080i_50Hz
342 Expand Ratio (Horizontal) 50Hz PIXEL 14 N/A 14 N/A
343 Position (Horizontal) 50Hz PIXEL 505 N/A 520 N/A
344 Position (Vertical) 50Hz PIXEL 384 N/A 384 N/A
345 Expand Ratio (Vertical) SCART PIXEL 5 N/A For SCART RGB 575i
346 Expand Ratio (Horizontal) SCART PIXEL 23 N/A Progressive OFF
347 Position (Horizontal) SCART PIXEL 518 N/A
348 Position (Vertical) SCART PIXEL 383 N/A
349 Expand Ratio (Vertical) 60Hz PIXEL N/A 2 N/A For Video and S-Video only
350 Expand Ratio (Horizontal) 60Hz PIXEL N/A 17 N/A Progressive ON
351 Position (Horizontal) 60Hz PIXEL N/A 513 N/A
352 Position (Vertical) 50Hz PIXEL N/A 383 N/A
353 Expand Ratio (Vertical) 50Hz PIXEL N/A 5
354 Expand Ratio (Horizontal) 50Hz PIXEL N/A 24
355 Position (Horizontal) 50Hz PIXEL N/A 522
356 Position (Vertical) 50Hz PIXEL N/A 383
357 Expand ratio (Vertical) 480i PIXEL N/A 2 N/A For Component 480i mode
358 Expand Ratio (Horizontal) 480i PIXEL N/A 17 N/A Progressive ON
359 Position (Horizontal) 480i PIXEL N/A 512 N/A
360 Position (Vertical) 480i PIXEL N/A 383 N/A
361 Expand ratio (Vertical) 575i PIXEL N/A 5 N/A For Component 575i mode
362 Expand Ratio (Horizontal) 575i PIXEL N/A 24 N/A Progressive ON
363 Position (Horizontal) 575i PIXEL N/A 519 N/A
364 Position (Vertical) 575i PIXEL N/A 383 N/A
365 Expand ratio (Vertical) SCART PIXEL 5 N/A For SCART RGB 575i
366 Expand Ratio (Horizontal) SCART PIXEL 23 N/A Progressive ON
367 Position (Horizontal) SCART PIXEL 518 N/A
368 Position (Vertical) SCART PIXEL 383 N/A
369 Expand ratio (Vertical) 60Hz PIXEL 10 N/A For RGB 480p
370 Expand Ratio (Horizontal) 60Hz PIXEL 33 N/A
371 Position (Horizontal) 60Hz PIXEL 508 N/A
372 Position (Vertical) 60Hz PIXEL 375 N/A
373 Expand ratio (Vertical) 50Hz PIXEL 21 N/A For RGB 575p
374 Expand Ratio (Horizontal) 50Hz PIXEL 30 N/A
375 Position (Horizontal) 50Hz PIXEL 512 N/A
376 Position (Vertical) 50Hz PIXEL 381 N/A
377 Expand Ratio (Vertical) SCART PIXEL 1 N/A For SCART RGB 480i
378 Expand Ration (Horizontal) SCART PIXEL 17 N/A Progressive ON
379 Position (Horizontal) SCART PIXEL 513 N/A
380 Position (Vertical) SCART PIXEL 384 N/A
381 Expand Ratio (Vertical) SCART PIXEL 2 N/A For SCART RGB 480i
382 Expand Ratio (Horizontal) SCART PIXEL 17 N/A Progressive ON
383 Position (Horizontal) SCART PIXEL 513 N/A
384 Position (Vertical) SCART PIXEL 383 N/A
400 Gamma Shift Combination ON/OFF 1 0: each source separate / 1: PC source only separate
401 PC Frame Lock Forced OFF 1 0: ON for all source / 1: OFF at PC
402 Auto Grayscale black control start point 31
403 Auto Grayscale black control limit point 16
405 Auto Grayscale white control start point 33
406 Auto Grayscale white control limit point 56
408 G-Gamma Shift Differential at Hi-Contrast
409 R-Gamma Shift Differential at Hi-Contrast
410 B-Gamma Shift Differential at Hi-Contrast
411 G-Gamma Shift Differential at Cinema
412 R-Gamma Shift Differential at Cinema
413 B-Gamma Shift Differential at Cinema
414
