Electrical Adjustments
● Service Adjustment Data Table
Initial
ItemNo. Name Device PC YCbCr Video Detail
480i(+) 480p(+) NTSC PAL Note: 480i(+) = 480i & 575i, 480p(+) = 480p & HDTV
These initial values are the reference data written from the
CPU ROM to memory IC when replaced new memory IC. The
adjustment items indicated with “
✻” are required to readjust
following to the “Electrical adjustments”. Other items should be
used with the initial data value.
1 G-VIDEOCNT M62392FP 140
2 R-VIDEOCNT M62392FP 140
✻ Video Center Adjustment ( = R/G/B-V1)
3 B-VIDEOCNT M62392FP 140
4 R-Sub-Bright L3E7070K0A 0
5 G-Sub-Bright L3E7070K0A 0 Sub-Bright Adjustment
6 B-Sub-Bright L3E7070K0A 0
7 G-Sub-Gain L3E7070K0A 530 530 530 530 530
8 R-Sub-Gain L3E7070K0A 530 530 530 530 530
✻ Gain Adjustment
9 B-Sub-Gain L3E7070K0A 5630 530 530 530 530
10 REF-G M62392FP 185
11 REF-R M62392FP 185
✻ Black Reference Adjustment
12 REF-B M62392FP 185
13 GVCOM L3E6100D0A 125
14 RVCOM L3E6100D0A 125
✻ Common Center Adjustment
15 BVCOM L3E6100D0A 125
16 G-Gamma-Shift L3E7070K0A 512 512 512 512 512
✻ Gamma Adjustment
17 R-Gamma-Shift L3E7070K0A 512 512 512 512 512
✻ White Balance Adjustment [R]
18 B-Gamma-Shift L3E7070K0A 512 512 512 512 512
✻ White Balance Adjustment [B]
20
21 G-V2 M62392FP 150
22 R-V2 M62392FP 150
✻ Video Center Adjustment (Link to Item No.1-3)
23 B-V2 M62392FP 150
24 SubBright PW168 128 128 128 128 128
25 SubColor PW168 85 85 85 N/A
26 SubTint PW168 128 128 128 N/A
27 -
28 SubBright (Video) VPC3230 N/A Note 1 N/A 128 127 Note 1: 575i = the same as PAL
29 SubCont (Video) VPC3230 N/A Note 1 N/A 50 51
30 SubColor (Video) VPC3230 N/A Note 1 N/A 2300 2450
31 SubTint (Video) VPC3230 N/A Note 1 N/A 512 512
32 SubBright (480i,575i) VPC3230 N/A 199 N/A 196 197
33 SubCont (480i,575i) VPC3230 N/A 25 N/A 26 26
34 SubColor (480i,575i) VPC3230 N/A 38 N/A 23 23 Note 2: 480i = the same as NTSC
35 SubColor (480i,575i) VPC3230 N/A 38 N/A 29 29 575i = the same as PAL
37 V-Line Color Shading Correction Setting (R1) L3E7070K0A 4 Vertical Line Color Shading Correction
38 V-Line Color Shading Correction Setting (R2) L3E7070K0A 3
39 V-Line Color Shading Correction Setting (R3) L3E7070K0A 0
40 V-Line Color Shading Correction Setting (G1) L3E7070K0A 4
41 V-Line Color Shading Correction Setting (G2) L3E7070K0A 3
42 V-Line Color Shading Correction Setting (G3) L3E7070K0A 0
43 V-Line Color Shading Correction Setting (B1) L3E7070K0A 4
44 V-Line Color Shading Correction Setting (B2) L3E7070K0A 3
45 V-Line Color Shading Correction Setting (B3) L3E7070K0A 0
46 R-Reference voltage (H) L3E7070K0A 820
47 R-Reference voltage (L) L3E7070K0A 250
48 G-Reference voltage (H) L3E7070K0A 820
49 G-Reference voltage (L) L3E7070K0A 250
50 B-Reference voltage (H) L3E7070K0A 820
51 B-Reference voltage (L) L3E7070K0A 250
52 Color Shading Correction ON/OFF L3E7070K0A 1
53 Lamp Life Time 0 Read only
54 Baud Rate 1 0: 9600 / 1: 19200 / 2: 38400
55 Shoot Out Mode 0 0: Normal / 1: Shoot out 1
56 Forced NOBRAND 0 0: Normal / 1: NOBRAND
57 LongCable 0 0:(Low)Normal 1:(High) Long Cable
58 Normal/Eco Switch 0 0:Normal Fixed 1:Eco Fixed
59 VSBEG PW168 1 Vertical Bound Correction
60 Ghost/Crosswalk L3E07070 15
61 Ghost Correction G L3E07070 10
62 Ghost Correction B L3E07070 10
63 Ghost Correction R L3E07070 10
64 TFT Panel Driver Enable G L3E07070 14
65 TFT Panel Driver Enable B L3E07070 14
66 TFT Panel Driver Enable R L3E07070 14
FAN CONTROL
80 Fan1 Min. Adjust M62393FP 5
81 Fan2 Min. Adjust M62393FP 5
✻ Fan Control Adjustment
82 Fan3 Min. Adjust M62393FP 5
✻ Fan Control Adjustment
83 Fan1 Max. Adjust M62393FP 229
