-9-
Initial
ItemNo. Name Device PC YCbCr Video Detail
480i(+) 480p(+) NTSC PAL Note: 480i(+) = 480i & 575i, 480p(+) = 480p & HDTV
-9-
84 Fan2 Max. Adjust M62393FP 229 ✻ Fan Control Adjustment
85 Fan3 Max. Adjust M62393FP 229
✻ Fan Control Adjustment
86 Fan Control Mode 0 0: Normal 1:High Land
87 Error Temp Change Time 3 in minutes
Normal Ceiling HighLand
88 Fan1 Min 65 65 70
89 Fan2 Min 90 95 100 Lowest Fan Operation Voltage in Normal
90 Fan3 Min 65 65 70
91 Fan1 Max 135 135 135
92 Fan2 Max 130 130 130 Highest Fan Operation Voltage in Normal
93 Fan3 Max 135 135 135
94 TempA Low 50 50 47 Operation Start in Normal for Temp Sensor 1
95 TempA High 54 54 52 Operation Stop in Normal for Temp Sensor 1
96 Eco Fan1 Min 60 60 65
97 Eco Fan2 Min 80 80 85 Lowest Fan Operation Voltage in Eco
98 Eco Fan3 Min 60 60 65
99 Eco Fan1 Max 120 120 125
100 Eco Fan2 Max 125 125 130 Highest Fan Operation Voltage in Eco
101 Eco Fan3 Max 125 125 130
102 Eco TempA Low 50 50 47 Operation Start in Eco for Temp Sensor 1
103 Eco TempA High 54 54 52 Operation Stop in Eco for Temp Sensor 1
104 TempA Error 57 57 55 Shutdown Temp of Temp Sensor 1
105 TempB Error 58 58 55 Shutdown Temp of Temp Sensor 2
106 TempC Error 70 70 70 Shutdown Temp of Temp Sensor 3
107 TempB-A Error 100 100 100 Shutdown Diff. Temp of Temp Sensor 2 and Sensor 1
108 TempC-A 100 100 100 Shutdown Diff. Temp of Temp Sensor 3 and Sensor 1
113 Manual Fan1 Voltage 100
114 Manual Fan2 Voltage 100 Fan Operation Voltage in Manual
115 Manual Fan3 Voltage 100
116 Temp Error Cooling Time 3 0: Continued 1: 30 sec. 2 60 sec. .....15:450 sec.
117 Cooling Time (L1) 3 0:30 sec. 2:60 sec. ....... 15:450 sec.
118 Fan2 Cooling front hald, Low speed spinning time setting 0 0:20 sec. 1: 22 sec. 3:26sec. .... 20:60 sec
119 Fan2 Cooling front hald, Low speed spinning Voltage setting 62 Operation Voltage for Fan2
120 Temp Sensor B Min Temp Condition at Temp Error(A-B) 45 Lowest Temp Condition of Temp Sensor 2 at Shutdown(1-2)
121 Normal Fan Mode 0 0:Auto Fan Control, 1: Manual Fan Control
122 Cooling Fan Mode 0
123 Service Fan Mode 0
124 Fan Over Cooling Prevent Mode On/Off 0 0: Normal 1: Over Cooling Prevent Mode
125 Eco Lamp Mode Lamp User Time in Eco Mode
126 Normal Lamp Time Lamp Use Time in Normal Mode
127 Projector Time Accumulated Projector user Time,Read Only
130 Cooling Time (L2) 4 1:30 sec. 2:60 sec. 3:90 sec. 4: 120 sec. ... 15:450 sec.
Normal Ceiling HighLand
131 Eco2 Fan 1 Min 60 60 65
132 Eco2 Fan 2 Min 80 80 85 Lowest Fan Operation Voltage in
Eco
133 Eco2 Fan 3 Min 60 60 65
134 Eco2 Fan 1
Max 120 120 125
135 Eco2 Fan 2
Max 125 125 130 Highest Fan Operation Voltage in Normal
136 Eco2 Fan 3
Max 125 125 130
137
Eco2 Temp A Low 50 50 47 Operation Start in Eco for Temp Sensor 1
138
Eco2 Temp A High 54 54 52 Operation Start in Eco for Temp Sensor 1
VPC3230
150 Notch Filter Select VPC3230 N/A Note 1 N/A 3 3 Note 1: 480i = the same as NTSC
151 Diagonal Dot Reduction VPC3230 N/A Note 1 N/A 1 1 575i = the same as PAL
152 Horizontal Differential Gain VPC3230 N/A Note 1 N/A 3 3
153 Vertical Differential Gain VPC3230 N/A Note 1 N/A 0 0
154 Vertical Peaking Gain VPC3230 N/A Note 1 N/A 7 7
155 AFC other1 VPC3230 N/A Note 1 N/A 540 540
156 AFC other2 VPC3230 N/A Note 1 N/A 536 536
157 Horizontal Peaking Filter VPC3230 N/A Note 1 N/A 1 1
158 Peaking Gain VPC3230 N/A Note 1 N/A 2 2
159 Peaking Filter Coring Enable VPC3230 N/A Note 1 N/A 0 0
161 Horizontal Lowpass Filter VPC3230 N/A Note 1 N/A 1 1
162 Horizontal Lowpass Filter Chroma VPC3230 N/A Note 1 N/A 0 0
163 DOR VPC3230 N/A Note 1 N/A 0 0
164 COR VPC3230 N/A Note 1 N/A 0 0
165 SGAIN VPC3230 N/A Note 1 N/A 28 28 SECAM=20
166 YC Delay VPC3230 N/A Note 1 N/A 62 62
167 DVCO Auto Adjust VPC3230 0 Execute auto adjustment when value changes 0 to 1.
168 DVCO Line-locked Center Frequency Adjust VPC3230 Note 1 2656
169 DVCO-Adjust VPC3230 Note 1 ReadOnly
TA1370
180 SEP. Level TA1370 02
181 HD1 OUT Set TA1370 3
182 HD Phase TA1370 29/29/36/38/36 1080i/1035i/720p/575p/480p
183 VD1 INV TA1370 0
