KD6-XU4800
-13-
Electrical Parts List
Electrical Parts List
● OUT OF CIRCUIT BOARD
Note: Parts order must contain Chassis No., Part No., and Descriptions.
F601
Fuse
SW902
Thermal Switch
FN905
Cooling Fan(G)
FN902
Cooling
Fan(Power)
Lamp Cover SW
Board
AV Board
Main Board
A901
Ballast Board
SP901
Speaker
R/C Board
FN904
Cooling Fan(R)
FN901
Cooling Fan(EX)
FN906
Cooling Fan(B)
FN903
Cooling Fan(PBS)
LP901
Lamp Ass’y
LF901
Noise Filter
Power Board
