Sanyo PLC-XW65K

73
Appendix
Terminal: Mini DIN 8-PIN
1
2
3
4
5
8 7 6
SERVICE PORT CONNECTOR
COMPUTER INPUT/COMPONENT INPUT/MONITOR OUTPUT TERMINAL (ANALOG)
Terminal : Analog RGB (Mini D-sub 15 pin)
5
1
2
34
10
9 678
15
14
13
11
12
Configurations of Terminals
Red (R/Cr/S-C) Input/R Output
Ground (Horiz.sync.)
Green (G/Y/S-Y) Input/G Output
-----
Blue (B/Cb/---) Input/B Output
Ground (Red)
Ground (Green)
Ground (Blue)
1
5
2
4
3
6
7
8
5V / ---
Horiz. sync. Input/Output (Composite H/V sync.Input)
Ground (Vert.sync.)
DDC data / ---
Ground
Vert. sync. Input/Output
DDC clock / ---
9
13
10
12
11
14
15
Serial
GND
R X D
PJN_DET
PJN_POW
-----
T X D
-----
4
1
3
2
5
6
7
-----
8
Appendix
Dimensions
10˚ MAX
5.51 (140)
7.45 (189)
1.20 (30.5)
2.76 (70)
10.39 (264)
1.89 (48)
2.58 (65.5)
4.33 (110) 4.80 (122)
0.65 (16.6)
3.35 (85)
Unit: inch(mm)
Screw Holes for Ceiling Mount
Screw: M4
Depth: 0.394(10.0)
