Controller PCB
Part No. POW-K181GJA
Controls Microprocessor
Control circuit fuse 250 V 3.15 A
Remote Control Unit RCS-2S4E
Fan & Fan Motor
Type Cross-flow
Q'ty ... Dia. and length mm 1 ... ø88 / L746
Fan motor model ... Q'ty UF2-31A5P-S ... 1
No. of poles ... rpm (240 V, High) 2 ... 1,440
Nominal output W 30
Coil resistance (Ambient temp. 20°C) Ω WHT-BRN : 133.7
WHT-PNK : 168.4
— —
— —
— —
Safety devices Type Thermal protector
Operating temp. Open °C 130±8
Close Automatic reclosing
Run capacitor µF 2.0
VAC 440
Flap Motor
Type Stepping motor
Model MP24GA2
Rating DC 12 V
Coil resistance (Ambient temp. 25°C) Ω Each terminals (1–2, 1–3, 1–4, 1–5) : 400 ± 7%
Heat Exch. Coil
Coil Aluminum plate fin / Copper tube
Rows 2
Fin pitch mm 1.3
Face area
