5
English
2. Installation Dimension Diagram
WARNING
Distance to ceiling
Distance to wall
Distance to floor
Distance to wall
Distance to wall
Distance to wall
15 cm
or more
150 cm
or more
50 cm
or more
300 cm
or more
15 cm or more
30 cm or more
200 cm or more
30 cm or more
50 cm or more
15 cm or more
Distance to nearby obstructions
The dimensions of the space necessary for correct
installation of the appliance including the minimum
permissible distances to adjacent structures.
To prevent abnormal heat generation
and the possibility of fire, do not place
obstacles, enclosures, or grilles in front of
or surrounding the air conditioner in a way
that may block air flow.
A
470 mm
470 mm
Model
299 mm SAP-CRV9AEH
SAP-CRV12AEH299 mm
B
Outdoor Unit Installation
Dimension
Air outlet side
Air intake side
A
B
Air outlet side
•
10-061 SAP-KRV9AEH EN 4/27/10 4:42 PM Page 5
