ADJUSTMENT
Cartridge
Mounting
(if
you
are
using
an
alternative
cartridge)
1.
Attach
the
cartridge
to
the
cartridge
shell
lightly,
using
screws
and
nuts
(Fig.
2).
Fig.
2
2.
Move
the
tone
arm
over
the
turntable
shaft
and
move the cartridge back or forth to obtain a space
of 19/32’’ (15 mm) between turntable shaft and
stylus tip (Fig. 3). Fix cartridge in this location by
tightening
mounting
screws.
Fig.
3
3.
Connect
the
leads
to
the
cartridge
terminals.
White
lead
..........
Left
(+)
Blue
lead
..........
Left
(—)
Red
lead
..........
Right
(+)
Green
lead
..........
Right
(—)
NOTE:
Recommended
weight
of
an
alternative
cartridge
assembly
(with
cartridge
shell)
are
12
g
to
18
g.
Lateral
Balancer
Mounting
(Fig.
4)
Center
HT
Fig.4
Horizontal Balance Adjustment
Turn
the
counter
weight
clockwise
—
or
counter-clockwise
and
balance
the
tone
arm
horizontally
(Fig.
5).
Fig.
5
Stylus
Pressure
Adjustment
1.
Turn
the
stylus
pressure
ring,
being
careful
not
to
turn
the
counter
weight,
and
set
for
zero
degree
on
the
ring
with
the
stylus
pressure
base
line
on
the
weight
shaft.
2.
Set
the
stylus
pressure
by
turning
the
counter
weight
to
the
number
recommended
for
your
cartridge
(Fig.
6).
Stylus
pressure
Counter
weight
base line
Pressure
ring
Fig.
6
Anti-Skating
Force
Adjustment
Set
the
anti-skating
to
the
number
previously
set
for
stylus
force
(Fig.
7).
Anti-skating
force
may
be
a
little
different
according
to
the
type
of
stylus
or
the
material
of
the
record
but
there
will
be
no
influence
on
the
record
performance.
Anti-skating
force
adjustment
knob
Fig.
7
Dust
Cover
Mounting
Fit the hinges of the dust cover to the notches on the
rear of the turntable base and then push down the
dust
cover
(Fig.
8).
