Sanyo VPC-MZ2EX Service Manual

27
R5134 401 224 8900 MT-GLAZE 100K JA 1/16W
R5135 401 225 0101 MT-GLAZE 27K JA 1/16W
R5136 401 224 9303 MT-GLAZE 1K JA 1/16W
R5137 401 224 9303 MT-GLAZE 1K JA 1/16W
R5139 401 275 5903 MT-GLAZE 10 DD 1/16W
R5140 401 262 2502 MT-GLAZE 68 DD 1/16W
R5141 401 283 7104 MT-GLAZE 100 DC 1/16W
R5143 401 226 5501 MT-GLAZE 120 JA 1/16W
R5144 401 226 5501 MT-GLAZE 120 JA 1/16W
R5145 401 235 1402 MT-GALZE 1.2K JA 1/16W
R5147 401 261 1508 MT-GLAZE 4.3K JA 1/16W
R5148 401 224 9006 MT-GLAZE 10K JA 1/16W
R5149 401 225 1405 MT-GLAZE 47K JA 1/16W
R5150 401 225 1405 MT-GLAZE 47K JA 1/16W
R5151 401 225 1405 MT-GLAZE 47K JA 1/16W
R5153 401 262 1000 MT-GLAZE 33K DC 1/16W
R5154 401 262 1307 MT-GLAZE 2.4K DC 1/16W
R5156 401 262 1000 MT-GLAZE 33K DC 1/16W
R5157 401 263 1900 MT-GLAZE 3.3K DC 1/16W
R5158 401 262 0607 MT-GLAZE 22K DC 1/16W
R5159 401 224 8900 MT-GLAZE 100K JA 1/16W
R5160 401 258 6606 MT-GLAZE 10K DC 1/16W
R5161 401 225 1405 MT-GLAZE 47K JA 1/16W
R5162 401 224 8900 MT-GLAZE 100K JA 1/16W
R5163 401 224 9006 MT-GLAZE 10K JA 1/16W
R5164 401 225 0507 MT-GLAZE 33K JA 1/16W
R5166 401 240 9509 MT-GLAZE 820 JA 1/16W
R5167 401 240 9509 MT-GLAZE 820 JA 1/16W
R5168 401 224 9600 MT-GLAZE 2.7K JA 1/16W
R5169 401 225 0705 MT-GLAZE 56K JA 1/16W
R5170 401 225 1702 MT-GLAZE 39K JA 1/16W
R5171 401 224 9006 MT-GLAZE 10K JA 1/16W
R5173 401 037 5004 MT-GLAZE 0.000 ZA 1/10W
R5174 401 224 8900 MT-GLAZE 100K JA 1/16W
R5175 401 224 9501 MT-GLAZE 2.2K JA 1/16W
R5176 401 237 2407 MT-GLAZE 270K JA 1/16W
R5179 401 225 1306 MT-GLAZE 470 JA 1/16W
R5180 401 225 1306 MT-GLAZE 470 JA 1/16W
R5181 401 225 1306 MT-GLAZE 470 JA 1/16W
R5182 401 275 2001 MT-GLAZE 30K DC 1/16W
R5183 401 258 6606 MT-GLAZE 10K DC 1/16W
R5185 401 284 5802 MT-GLAZE 16K DC 1/16W
R5186 401 263 2105 MT-GLAZE 5.1K DC 1/16W
R9201 401 224 9006 MT-GLAZE 10K JA 1/16W
R9501 401 203 3803 MT-GLAZE 1 JA 1/16W
R9502 401 203 3803 MT-GLAZE 1 JA 1/16W
R9503 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R9505 401 225 0606 MT-GLAZE 5.6K JA 1/16W
R9506 401 225 0606 MT-GLAZE 5.6K JA 1/16W
R9507 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R9508 401 225 0705 MT-GLAZE 56K JA 1/16W
R9509 401 038 0008 MT-GLAZE 200 JA 1/10W
R9510 401 038 0008 MT-GLAZE 200 JA 1/10W
R9511 401 226 1503 MT-GLAZE 0.000 ZA 1/16W
R9512 401 225 0705 MT-GLAZE 56K JA 1/16W
R9542 401 224 7804 MT-GLAZE 2.7 JA 1/16W
R9543 401 224 8900 MT-GLAZE 100K JA 1/16W
R9545 401 224 7804 MT-GLAZE 2.7 JA 1/16W
R9546 401 037 5004 MT-GLAZE 0.000 ZA 1/10W
R9801 401 224 9006 MT-GLAZE 10K JA 1/16W
R9802 401 224 9006 MT-GLAZE 10K JA 1/16W
R9803 401 037 5004 MT-GLAZE 0.000 ZA 1/10W
(FUSES)
PR511 423 029 3706 FUSE 32V 2.5A
PR512 423 028 1307 FUSE 32V 1.5A
PR513 423 028 0904 FUSE 32V 2A
PR981 423 028 0904 FUSE 32V 2A
(MISCELLANEOUS)
636 062 4375 SPACER FL CONDENCER-SX212
(CONNECTORS)
CN171 645 045 4417 SOCKET,24P (N.S.P)
CN172 645 024 8184 PLUG,26P (N.S.P)
CN173 645 024 8184 PLUG,26P (N.S.P)
CN175 645 025 1320 PLUG,2P (N.S.P)
CN531 645 005 6901 PLUG,SIDE-ZR-SM3 (N.S.P)
CN951 645 045 4400 SOCKET,18P (N.S.P)
CN981 645 002 2876 PLUG,2P (N.S.P)
COMPL PWB,PW-1
636 064 1853
(SEMICONDUCTORS)
Q5001 405 115 5207 TR 2SC4617 R
Q5002 405 129 2308 TR UMZ1N
Q5003 405 148 7100 TR CPH6401
Q5004 405 163 2302 TR CPH3307
Q5005 405 129 2704 TR UMH9N
Q5006 405 162 4109 TR CPH6311
Q5007 405 153 4606 TR 2SA2013
Q5008 405 129 2308 TR UMZ1N
Q5009 405 148 7100 TR CPH6401
Q5010 405 148 6905 TR CPH3303
Q5011 405 115 6907 TR DTC114EE
Q5012 405 157 1403 TR 2SA2018
Q5013 405 129 2902 TR UMH11N
Q5014 405 129 2308 TR UMZ1N
Q5015 405 148 3904 TR CPH3209
Q5016 405 157 1403 TR 2SA2018
Q5019 405 129 2308 TR UMZ1N
Q5020 405 148 7100 TR CPH6401
Q5021 405 157 1403 TR 2SA2018
Q5022 405 115 6907 TR DTC114EE
Q5401 405 115 7508 TR DTC123JE
Q5402 405 115 6907 TR DTC114EE
Q5405 405 150 6603 TR CPH3210
Q5406 405 150 5002 TR CPH3109
Q5407 405 115 5207 TR 2SC4617 R
Q5409 405 165 9200 TR GT8G131
(INTEGRATED CIRCUITS)
IC501 409 417 8300 IC LA5627W
IC502 409 466 6203 IC TK73200
(DIODES)
D5001 407 205 5203 DIODE RB521S-30
D5002 407 201 2701 DIODE RB051L-40
D5003 407 209 1706 DIODE RB081L-20
D5004 407 201 2701 DIODE RB051L-40
D5005 407 210 9401 DIODE RB491D
D5006 407 203 5601 DIODE RB461F
D5007 407 210 5403 DIODE RB551V-30
D5009 407 205 5203 DIODE RB521S-30
D5402 407 202 0300 DIODE F1F16
D5403 407 122 2606 DIODE SFPM-64
D5404 407 202 0102 DIODE F1SN4
D5405 407 199 4503 DIODE CR08AS-8-T1
D5407 407 162 8507 DIODE DAN222
D5410 407 162 8507 DIODE DAN222
(VARIABLE RESISTORS)
VR501 645 028 2249 VR,SEMI,3.3K S
VR502 645 028 2201 VR,SEMI,2.2K S
VR503 645 028 2201 VR,SEMI,2.2K S
VR504 645 028 2201 VR,SEMI,2.2K S
VR505 645 028 2201 VR,SEMI,2.2K S
(INDUCTORS)
L5001 645 037 1530 INDUCTOR,47U K
L5002 645 036 7496 INDUCTOR,4.7U M
L5003 645 037 0625 INDUCTOR,4.7U M
L5004 645 046 1941 INDUCTOR,10U M
L5005 645 037 0625 INDUCTOR,4.7U M
L5006 645 037 1523 INDUCTOR,10U K
L5008 645 037 0625 INDUCTOR,4.7U M
L5009 645 037 1523 INDUCTOR,10U K
L5010 645 030 5887 INDUCTOR,1000 OHM
L5012 645 037 1523 INDUCTOR,10U K
L5401 645 036 4938 INDUCTOR,10U M
(TRANSFORMERS)
T5401 645 032 8831 TRANS,STEP UP
T5402 645 031 6951 TRANS,STEP UP
(CAPACITORS)
C5001 403 155 2309 CERAMIC 4700P K 50V
C5002 403 338 4403 CERAMIC 0.1U K 16V
C5003 403 343 3101 CERAMIC 1U K 6.3V
C5004 403 343 3101 CERAMIC 1U K 6.3V
C5005 403 169 2807 CERAMIC 330P J 50V
C5006 403 338 4403 CERAMIC 0.1U K 16V
C5007 403 155 1807 CERAMIC 0.01U K 25V
C5008 403 155 1807 CERAMIC 0.01U K 25V
C5009 403 335 4703 CERAMIC 0.22U K 6.3V
C5010 403 342 7506 CERAMIC 1000P J 50V
C5011 403 342 7506 CERAMIC 1000P J 50V
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
