Sanyo VPC-MZ2EX Service Manual

28
C5012 403 155 1807 CERAMIC 0.01U K 25V
C5013 403 343 3101 CERAMIC 1U K 6.3V
C5014 403 325 6304 CERAMIC 0.22U K 10V
C5015 403 155 1807 CERAMIC 0.01U K 25V
C5016 403 335 1405 CERAMIC 10U K 6.3V
C5017 403 320 0604 CERAMIC 220P J 25V
C5018 403 367 6607 POS-SOLID 47U M 6.3V
C5019 403 283 5708 CERAMIC 2200P K 50V
C5020 403 367 6607 POS-SOLID 47U M 6.3V
C5021 403 367 6607 POS-SOLID 47U M 6.3V
C5022 403 338 2904 CERAMIC 0.47U K 10V
C5023 403 338 4403 CERAMIC 0.1U K 16V
C5024 403 276 1304 CERAMIC 1000P K 50V
C5025 403 372 3202 CERAMIC 22U M 6.3V
C5026 403 372 3202 CERAMIC 22U M 6.3V
C5027 403 335 1405 CERAMIC 10U K 6.3V
C5028 403 320 0604 CERAMIC 220P J 25V
C5029 403 367 6607 POS-SOLID 47U M 6.3V
C5030 403 276 1304 CERAMIC 1000P K 50V
C5031 403 335 1405 CERAMIC 10U K 6.3V
C5032 403 335 1405 CERAMIC 10U K 6.3V
C5033 403 343 3101 CERAMIC 1U K 6.3V
C5034 403 309 2407 CERAMIC 82P J 50V
C5035 403 343 3101 CERAMIC 1U K 6.3V
C5036 403 335 1405 CERAMIC 10U K 6.3V
C5037 403 335 1405 CERAMIC 10U K 6.3V
C5038 403 279 5002 CERAMIC 4700P K 25V
C5039 403 343 3101 CERAMIC 1U K 6.3V
C5040 403 335 1405 CERAMIC 10U K 6.3V
C5043 403 335 1405 CERAMIC 10U K 6.3V
C5044 403 320 0604 CERAMIC 220P J 25V
C5045 403 333 3708 CERAMIC 10U M 10V
C5046 403 279 5002 CERAMIC 4700P K 25V
C5047 403 333 3708 CERAMIC 10U M 10V
C5048 403 343 3101 CERAMIC 1U K 6.3V
C5401 403 367 6607 POS-SOLID 47U M 6.3V
C5403 403 350 2005 CERAMIC 0.15U K 10V
C5404 403 276 1304 CERAMIC 1000P K 50V
C5406 403 343 3101 CERAMIC 1U K 6.3V
C5407 403 276 1007 CERAMIC 0.01U K 16V
C5409 403 284 7701 CERAMIC 0.033U Z 16V
C5410 403 341 4407 CERAMIC 0.047U K 350V
C5411 403 330 5903 CERAMIC 0.01U K 500V
C5414 403 279 5002 CERAMIC 4700P K 25V
(RESISTORS)
R5001 401 224 9303 MT-GLAZE 1K JA 1/16W
R5002 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R5003 401 224 9303 MT-GLAZE 1K JA 1/16W
R5004 401 258 0406 MT-GLAZE 120K DC 1/16W
R5005 401 258 9300 MT-GLAZE 220K DC 1/16W
R5006 401 258 9300 MT-GLAZE 220K DC 1/16W
R5007 401 258 0406 MT-GLAZE 120K DC 1/16W
R5008 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R5009 401 224 9303 MT-GLAZE 1K JA 1/16W
R5010 401 224 9303 MT-GLAZE 1K JA 1/16W
R5011 401 262 2304 MT-GLAZE 1.0K DC 1/16W
R5012 401 262 5206 MT-GLAZE 1.5K DC 1/16W
R5013 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R5014 401 258 0406 MT-GLAZE 120K DC 1/16W
R5015 401 258 9300 MT-GLAZE 220K DC 1/16W
R5016 401 258 9102 MT-GLAZE 5.6K DC 1/16W
R5017 401 258 0406 MT-GLAZE 120K DC 1/16W
R5018 401 258 9300 MT-GLAZE 220K DC 1/16W
R5019 401 224 9402 MT-GLAZE 1.0M JA 1/16W
R5020 401 262 2304 MT-GLAZE 1.0K DC 1/16W
R5021 401 262 5206 MT-GLAZE 1.5K DC 1/16W
R5022 401 224 9303 MT-GLAZE 1K JA 1/16W
R5023 401 235 1402 MT-GALZE 1.2K JA 1/16W
R5024 401 225 1603 MT-GLAZE 390 JA 1/16W
R5025 401 225 8008 MT-GLAZE 330 JA 1/16W
R5026 401 225 1306 MT-GLAZE 470 JA 1/16W
R5027 401 261 1508 MT-GLAZE 4.3K JA 1/16W
R5028 401 224 9006 MT-GLAZE 10K JA 1/16W
R5029 401 224 8900 MT-GLAZE 100K JA 1/16W
R5030 401 224 9303 MT-GLAZE 1K JA 1/16W
R5031 401 283 8903 MT-FILM 0.22 FA 1/4W
R5032 401 224 9303 MT-GLAZE 1K JA 1/16W
R5033 401 262 1000 MT-GLAZE 33K DC 1/16W
R5034 401 269 3908 MT-GLAZE 4.7K DC 1/16W
R5035 401 224 8900 MT-GLAZE 100K JA 1/16W
R5036 401 224 9303 MT-GLAZE 1K JA 1/16W
R5037 401 224 9006 MT-GLAZE 10K JA 1/16W
R5038 401 224 9303 MT-GLAZE 1K JA 1/16W
R5039 401 262 5602 MT-GLAZE 56K DC 1/16W
R5040 401 263 2006 MT-GLAZE 8.2K DC 1/16W
R5041 401 257 4009 MT-GLAZE 68K DC 1/16W
R5042 401 235 1402 MT-GALZE 1.2K JA 1/16W
R5043 401 225 1603 MT-GLAZE 390 JA 1/16W
R5044 401 225 8008 MT-GLAZE 330 JA 1/16W
R5045 401 225 1306 MT-GLAZE 470 JA 1/16W
R5046 401 261 1508 MT-GLAZE 4.3K JA 1/16W
R5047 401 224 9006 MT-GLAZE 10K JA 1/16W
R5048 401 224 8900 MT-GLAZE 100K JA 1/16W
R5049 401 224 9303 MT-GLAZE 1K JA 1/16W
R5050 401 224 9303 MT-GLAZE 1K JA 1/16W
R5051 401 262 1000 MT-GLAZE 33K DC 1/16W
R5052 401 269 3908 MT-GLAZE 4.7K DC 1/16W
R5053 401 224 8900 MT-GLAZE 100K JA 1/16W
R5054 401 224 9501 MT-GLAZE 2.2K JA 1/16W
R5055 401 235 1402 MT-GALZE 1.2K JA 1/16W
R5056 401 226 5501 MT-GLAZE 120 JA 1/16W
R5057 401 226 5501 MT-GLAZE 120 JA 1/16W
R5059 401 261 1508 MT-GLAZE 4.3K JA 1/16W
R5060 401 224 9006 MT-GLAZE 10K JA 1/16W
R5061 401 224 8900 MT-GLAZE 100K JA 1/16W
R5062 401 224 9501 MT-GLAZE 2.2K JA 1/16W
R5063 401 224 9303 MT-GLAZE 1K JA 1/16W
R5064 401 262 1000 MT-GLAZE 33K DC 1/16W
R5065 401 262 1703 MT-GLAZE 2.7K DC 1/16W
R5066 401 225 8008 MT-GLAZE 330 JA 1/16W
R5067 401 225 1603 MT-GLAZE 390 JA 1/16W
R5068 401 235 1402 MT-GALZE 1.2K JA 1/16W
R5069 401 225 1306 MT-GLAZE 470 JA 1/16W
R5070 401 261 1508 MT-GLAZE 4.3K JA 1/16W
R5071 401 224 9006 MT-GLAZE 10K JA 1/16W
R5072 401 224 8900 MT-GLAZE 100K JA 1/16W
R5073 401 224 9501 MT-GLAZE 2.2K JA 1/16W
R5074 401 224 9303 MT-GLAZE 1K JA 1/16W
R5075 401 262 1000 MT-GLAZE 33K DC 1/16W
R5076 401 262 1703 MT-GLAZE 2.7K DC 1/16W
R5401 401 224 9303 MT-GLAZE 1K JA 1/16W
R5408 401 229 3900 MT-GLAZE 180 JA 1/16W
R5409 401 224 9105 MT-GLAZE 150 JA 1/16W
R5410 401 225 7902 MT-GLAZE 220 JA 1/16W
R5411 401 224 9006 MT-GLAZE 10K JA 1/16W
R5412 401 227 2400 MT-GLAZE 15 JA 1/16W
R5413 401 224 9006 MT-GLAZE 10K JA 1/16W
R5414 401 224 9303 MT-GLAZE 1K JA 1/16W
R5417 402 078 4407 MT-GLAZE 10M FKG 1/8W
R5418 401 226 5402 MT-GLAZE 56 JA 1/16W
R5419 401 262 1208 MT-GLAZE 82K DC 1/16W
R5422 402 079 0200 MT-GLAZE 220K JKG 1/8W
R5423 401 225 0309 MT-GLAZE 33 JA 1/16W
R5424 401 226 5402 MT-GLAZE 56 JA 1/16W
R5425 402 077 7409 MT-GLAZE 100K JKG 1/8W
R5426 401 225 9005 MT-GLAZE 470K JA 1/16W
R5429 401 224 9006 MT-GLAZE 10K JA 1/16W
R5470 401 225 1306 MT-GLAZE 470 JA 1/16W
R5471 401 225 1306 MT-GLAZE 470 JA 1/16W
R5472 401 225 7902 MT-GLAZE 220 JA 1/16W
(FUSES)
PR501 423 028 0904 FUSE 32V 2A
PR503 423 029 3706 FUSE 32V 2.5A
PR504 423 029 3706 FUSE 32V 2.5A
PR505 423 029 3706 FUSE 32V 2.5A
(MISCELLANEOUS)
636 061 3768 HOLDER FLASH-SX212/J
645 046 9343 ASSY,LAMP,SX212
(CONNECTORS)
CN501 645 009 9892 SOCKET,PWB-PWB 30(N.S.P)
COMPL PWB,SY-1
636 064 1822
(SEMICONDUCTORS)
Q3001 405 138 5703 TR DTA124EUA
OR 405 119 1007 TR UN5112
OR 405 078 6105 TR 2SA1677
(INTEGRATED CIRCUITS)
IC301 410 435 2300 IC UPD780022AGK-B61-9ET
IC302 409 383 1008 S-8423NFS
LOCATION PARTS NO. DESCRIPTION LOCATION PARTS NO. DESCRIPTION
