2. Router_B LAN PC will get IP address from Router_A.
If you failed the WDS setting, please check you setting with refer to the list below.
Note 1: LAN IP address should be under the same segment but cannot be the same number.
Router_A Router_B
Wireless Mode AP+WDS WDS
LAN IP Address Set the same segment as the
router B(Note 1)
Example :192.168.1.1
Set the same segment as the
router_A(Note 1)
Example :192.168.1.2
Security Set the same security as
Router_B
Set the same security as
Router_A
DHCP Enable Disable
MAC Address Same as Router B Same as Router A
Router_A mac address
Select encryption for security
