14 Entris
®
BCE Operating Instructions
Installation
4.4.2 “Toggle Between Weight Units” Menu Structure
t Navigating in menus (see Chapter 4.5, page 14).
Level 1 Description
Unit 1 - unit 4 Define the displayed weight unit and the
resolution for the 1st to 4th convertible
unit.
4.5 Navigating the Menus
Procedure
t To open the main menu: Press the [Menu]
button.
t To display menu items or parameters of a
level: Press the [Up] or [Down] button.
t To return to the next higher menu level or
exit the menu: Press the [Back] button.
t To open a displayed menu level or a
displayed parameter: Press the [Confirm]
button.
5 Installation
5.1 Scope of Delivery
Item Quantity
Device 1
Pan support 1
Frame draft shield 1
Power supply unit with country-specific
AC adapters
1
Operating Instructions 1
Shock absorber 4
5.2 Selecting an Installation Site
Procedure
t Make sure that the following conditions are met at the
installation site:
Condition Features
Ambient
conditions
− Suitability tested (ambient conditions
see Chapter 15.1, page 35)
Setup surface − Stable, even surface with little vibration
− Sufficient space for the device (device
space requirements see Chapter “15.9
Device Dimensions”, page 37).
− Sufficient load bearing capacity for the
device (device weight see Chapter
“15.10 Metrological Data”, page 38).
Access to parts
relevant to
operation
Convenient and safe
