4
Setting up the Balance/Scale
Basic
lite
Balances with a Glass Draft Shield:
§ Place the components listed below on
the balance in the order given:
– Shield ring – place it on the balance so that
the edge for fitting the glass draft shield faces
upwards and turn it until it is firmly in place.
– Pan support
– Weighing pan
– Glass draft shield
– Draft shield cover
Basic
lite
Balances/Gold Scales with
a Round Weighing Pan
§ Place the components listed below on the
balance in the order given:
– Pan support
– Weighing pan/load plate
Basic
lite
Balances/Gold Scales with
a Rectangular Weighing Pan
§ Place the weighing pan/load plate on the
balance/scale
Connecting the Balance/Scale to AC Power/
Safety Precautions
Use only
– Original Sartorius AC adapters
§ Insert the right-angle plug into the jack
§ The AC adapter rated to Class 2 can be
plugged into any wall outlet without requiring
any additional safety precautions
The ground is connected to the balance/scale
housing, which can be additionally grounded
for operation.
