108 Operating Instructions Combics Indicators
Data Interfaces
Example: Output weight value of +1255.7 g
Position 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
+ * * * 1 2 5 5 . 7 * g * * CR LF
Position 1: Plus +, or minus - or space
Position 2: Space
Positions 3-10: Weight value with decimal point; leading zeros are output as
spaces.
Position 11: Space
Positions 12-14: Characters for unit of measure, space or ! sign as a symbol
Position 15: Carriage return
Position 16: Line feed
Data Output Format with 22 Characters
Normal Operation
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
K K K K K K + A A A A A A A A A * E E E CR LF
K K K K K K - A A A A A A A A A * E E E CR LF
* * * * * * * * * * * * * * * * * * * * CR LF
K: ID code character, right-justifi ed with spaces
+-: Plus or minus sign
*: Space
A: Digit or letter (max. 7 characters plus decimal point)
E: Unit symbol (1 to 3 letters followed by 2-0 spaces)
CR: Carriage return
LF: Line feed
Special Codes
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22
S t a t * * * * * * * * - - * * * * * * CR LF
S t a t * * * * * * * * H * * * * * * * CR LF
S t a t * * * * * * * * H H * * * * * * CR LF
S t a t * * * * * * * * L * * * * * * * CR LF
S t a t * * * * * * * * L L * * * * * * CR LF
S t a t * * * * * * * * C * * * * * * * CR LF
*: Space
– –: Final readout
H: Overload
HH: Overload in checkweighing
L: Underweight
L L: Underweight in checkweighing
C: Calibration/Adjustment
