Operating Instructions Combics Indicators 123
Product Order No.
Combics 2: Replacement 1st weighing point/scale connection
instead of internal A/D converter (3000e)
Analog platform 10,000e YDI02C-WPA
RS-232 interface for digital platform YDI02C-WPD
RS-485 interface for digital platform YDI02C-WPD
2nd weighing point/scale connection
Analog platform 10,000e YDI02C-WPA
RS-232 interface for digital platform YDI02C-WPD
RS-485 interface for digital platform YDI02C-WPD
External interface adapter
Connection cable from RS-232 data interface to USB
interface on the PC, D-SUB plug 25-pin, 2 m
1)
YCC01-USBM2
Digital input/output module to connect Combics 2 to external
control units, with 8 open collector outputs (50 mA) and
7 TTL-compatible inputs (0 - 30 V),
YCC02-RELAIS01/02 connection cable required YSB02
Relay box to connect Combics 2 to external control units,
YCC02-RELAIS01/02 connection cable required VF3033
Software
SNLE Sartorius Nice Label Express Software YAD02IS
WinScale for Windows YSW03
SartoCollect YSC02
Other functions
Guard covers (x2) YDC01CI
IP65 kit for cable connections (D-SUB 25) on request
Cable gland for cables with diameter 4.5 to 9 mm, M16 x 1.5 YAS04CIS
Kit for control panel installation
2)
YAS07CI
Plug and socket set to connect similar weighing platforms
to indicators (separable connection) YAS99I
Stainless steel cable connection box for connecting up to
4 load cells in one platform or for external assembly,
PR6130/64S 940536130642
Relay box to connect scale to external control units
with 4 (5), relay outputs (250V/3A) and 1
optocoupler input (0 - 30V) YSB01
Peripheral devices
Control display red/green/red YRD14Z
Remote display for Combics CAISL indicators YRD02Z
Remote display, 7-segment, up to 45 mm character size on request
Barcode scanner, 120 mm scanning width, with cable
for connection to CAISL2 YBR03PS2
Foot switch, incl. D-Sub 25-pin T-connector YFS01
Hand switch, incl. D-Sub 25-pin T-connector YHS02
Flow control for pumps with analog or pulse interface YFC02Z-V2
Flexible formatting options for printouts
(e.g., barcodes, variable font sizes, graphics, etc.) on request
1) Model CAISL only
2) Suitable for use in zones 2 + 22
Accessories
